Fleet Grade Reflective Film

DPF 2400, is a Gloss premium digitally reflective film, has a conformable formulation for fleet and vehicle applications. A brilliantly bright white point and a uniform visual appearance during the night (and day!) will make any graphic shine. The DPF 2400XLP adds Arlon's Flite Adhesive air egress technology to help eliminate bubbles during applications.

Arlon DPF 4500 Product Description

For full and partial fleet wraps, vehicle markings and any surface requiring reflective vinyl film.
Recommended with dry application methods only.
Speedy Installation with X-Scape Technology®.
Exceptional Repositionability, Minimizing Bruising for Optimal Reflectivity.
Enhanced Elongation for Optimum Conformability.
Brilliant Graphics by Day, Luminous Graphics by Night.
World-Class Printability - Compatible with Solvent, Latex, and UV.

Property	Test Methods	Typical Value
Surface Finish	Gloss Meter 60° Reflection	80 to 90 Gloss Units
Thickness	Micrometer, Federal Bench Type	5-mil (125 micron)
Tensile Strength	Tensile Tester with 51 mm jaw separation; crosshead speed of 5.1 mm/s, web direction	≥ 10.0 lb/in
Elongation	Instron Tensile Tester as above	≥ 90%
Shelf Life	Ideal Storage Temperature 21°C and 50% relative humidity	2 years from factory shipment
Application Temperature Range	On clean, dry substrate	50°F to 100°F
Service Temperature Range	On clean, dry substrate	-40°F to 160°F
Dimensional Stability	70°C, 48 hours	< 10 mils
Gasoline Resistance	Film applied to etched aluminum panels 24 hours prior to testing LS-300 Method 4.4.6	No appreciable effect
Peel Adhesion	PSTC-1, 15 min. 21°C on Stainless Steel	≥ 4.2 lbs/in
Liner Release	TLMI Release at 90°, 60 cm/min	40 g/2 in
