General Formulations CC500 Cut & Craft vinyl is the most economical vinyl we carry. Even though it is sold for a low price, there is no performance drop as this is an excellent 3 mil, 5 year outdoor vinyl. It cuts and weeds very well and is easy to work with. CC500 has a High Gloss finish and is available in 44 colors.
| Property | Test Methods | Typical Value | |
|---|---|---|---|
| Surface Finish | Colors: Gloss Meter 60° Reflection | ≥80 Gloss Units | |
| Thickness | Micrometer, Federal Bench Type | 3.0-mil (76 micron) | |
| Tensile Strength | Tensile Tester with 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction | ≥3500+ MD | ≥3500+ CD |
| Elongation | Percentage | MD ≥200 / CD ≥200 | |
| Shelf Life | Free from excessive moisture, temperature, direct sunlight | Up to 1 year | |
| Application Temperature Range | On clean, dry substrate | ≥40°F | ≥4.4°C |
| Service Temperature Range | Film applied to etched aluminum panels 24 hours prior to testing | -40°F to 180°F | -40°C to 82°C |
| Dimensional Stability | 158°F (70°C), 48 hours | MD ≤2mm | CD ≤1.2mm |
| Peel Adhesion | PSTC-1, 15 min, RT 72°F (23°C) | ≥ 40 oz/in | ≥ 0.45 kg/cm |
| Liner Release | @ 360” / min (g/2”) | 30-70 | |
| Opacity | Percentage | 94 % | (average - varies by color) |
| Film Weight | Grams per Square Meter | 104 | |
Cut & Craft Selection Guide
Colors displayed on screen may not be a 100% color match of actual material.
