Multi-Purpose Urethane Protection

Series 3310 is a 1.5-mil (38 micron) polyurethane film with a clear, permanent pressure-sensitive adhesive. An environmentally friendly, premium polyurethane overlaminate, Series 3310 offers the highest standard in protection. With outdoor durability up to 10 years on vertical applications, Series 3310 can be used on digitally printed PVC media and flexible substrates. When compared with similar overlaminates, Series 3310 delivers enhanced clarity, superior conformability, high-gloss levels and extra durability.

Series 3310 Product Description

Protective overlaminate for digitally printed PVC media and flexible substrates.
Protective overlaminate SLX™ Cast Wrap, DPF 6100XLP, DPF 6000XRP, DPF 6000RP White, DPF 6500, and DPF 6700.
Fleet graphics and vehicle applications.
Improved clarity than PVC overlaminates.
Superior conformability.
Increased durability & UV protection to extend the life of your graphic.
Arlon overlaminate film is designed to be laminated cold without any heat.

Property	Test Methods	Typical Value
Surface Finish	Gloss Meter 60° Reflection	80 Gloss Units
Thickness	Micrometer, Federal Bench Type	1.5-mil (38 micron)
Tensile Strength	Tensile Tester 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction	19 lb/in	3.4 kg/cm
Elongation	Instron Tensile Tester as above	400% to 450%
Shelf Life (In Box)	Ideal storage temperature (70°F/21°C)	2 years from factory shipment
Application Temperature Range	On clean, dry substrate	60°F to 90°F	16°C to 32°C
Service Temperature Range	On clean, dry substrate	-40°F to 175°F	-40°C to 79°C
Dimensional Stability	158°F (70°C), 48 hours	5-mil	0.12 mm
Peel Adhesion	PSTC-1, 15min 70°F (21°C)	3.5 - 4.5 lb/in	0.63 - 0.80 kg/cm
Liner Release	TLMI Release at 90°, 300 in/min (760 cm/min)	37 g/2 in	7.28 g/cm
