Arlon Series 3350 Anti Graffiti Laminate from Ordway Sign Supply, Inc.

Series 3350 Product Description

Long-term signage, kiosks and POP displays.
Safety signs and nameplates.
Fleet and vehicle applications (flat surfaces only), farm and construction equipment markings, automotive striping and model identification and decorations for railway car, bus, boat and
recreational vehicles.
Protective overlaminate for most DPF and screenprint films.
UV Inhibitors for improved weathering.
Product Compatibility: Series 3350 is not recommended for overlaminating over flexible substrates.
Arlon overlaminate film is designed to be laminated cold without any heat.

Property	Test Methods	Typical Value
Surface Finish	Gloss Meter 60° Reflection	40 to 60 Gloss Units
Thickness	Micrometer, Federal Bench Type	2-mil (50 micron)
Tensile Strength	Tensile Tester 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction	10 lb/in	1.8 kg/cm
Elongation	Instron Tensile Tester as above	≥ 50%
Shelf Life (In Box)	Ideal Storage Temperature 70°F (21°C) and 50% relative humidity	2 years from factory shipment
Application Temperature Range	On clean, dry substrate	60°F to 90°F optimum	16°C to 32°C optimum
Service Temperature Range	On clean, dry substrate	-40°F to 225°F	-40°C to 107°C
Dimensional Stability	158°F (70°C), 48 hours	0.005 in	0.12 mm
Peel Adhesion	PSTC-1, 15 min, 70°F (21°C)	≥ 3.11 lb/in	≥ 0.60 kg/cm
Liner Release	TLMI Release at 90°, 300 in/min (760 cm/min)	25 g/2 in	10 g/cm
