Promotional Calendered Overlaminate

Every graphic deserves to be center stage, and a short-term graphic is no different. Series 3510 overlaminate is the perfect match for any of our DPF 510 products. Designed with protection in mind, Series 3510 overlaminate will extend the life of your promotional graphic giving it the well-deserved spotlight that it needs. Available in either a Gloss or Matte finish to suit your preference.

Series 3510 Product Description

Protective overlaminate for all promotional calendered products
Short-term signage, kiosks and POP displays
Ideal for interior and exterior applications on flat surfaces
Arlon overlaminate film is designed to be laminated cold without any heat

Property	Test Methods	Typical Value
Surface Finish	Gloss Meter 60° Reflection	Gloss: 70 to 90 Gloss Units Matte: 1.5 to 10 Gloss Units
Thickness	Micrometer, Federal Bench Type	3.2-mil (80 micron)
Tensile Strength	Tensile Tester with 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction	≥ 15 lb/in	≥ 2.68 kg/cm
Elongation	Instron Tensile Tester as above	≥ 250%
Shelf Life (In Box)	Ideal Storage Temperature 70°F (21°C) and 50% relative humidity 1	year from factory shipment
Application Temperature Range	On clean, dry substrate	50°F to 90°F 1	0°C to 32°C
Service Temperature Range	Film applied to etched aluminum panels 24 hours prior to testing	-20°F to 150°F	-29°C to 65°C
Dimensional Stability	158°F (70°C), 48 hours, on aluminum panel	5-mil	0.13 mm
Peel Adhesion	PSTC-1, 15 min, 70°F (21°C)	≥ 1.5 lb/in	≥ 0.27 kg/cm
Peel Adhesion	PSTC-1, 24 hrs, 70°F (21°C)	10.7N/.98in	10.7N 25/mm
Liner Release	TLMI Release at 90°, 300 in/min (760 cm/min)	125 g/2 in	24.6 g/cm
