Series 3200 Optically Clear Gloss overlaminate will not only protect, but also prolong the life of printed graphics for up to 2 years. This is your ideal overlaminate for window applications, or graphics that demand perfect clarity. Seeing is believing.
Protective overlaminate for DPF 45WF, DPF 47WF and DPF 2400
Also compatible with cast print media DPF 6100XLP, DPF 6000XRP, DPF 6000RP White, DPF 6000RP Clear, DPF 6500, DPF 6700, DPF 4500G Clear and DPF 50WD Clear/White
Any glass or transparent surfaces
Reflective wraps
Perforated window film overlaminate for building, bus, automotive and flat glass
UV inhibitors to protect and extend the life of your printed graphic
Arlon overlaminate film is designed to be laminated cold without any heat
| Property | Test Methods | Typical Value | |
|---|---|---|---|
| Surface Finish | Gloss Meter 60° Reflection | ≥ 90 Gloss Units (crystal) | |
| Thickness | Micrometer, Federal Bench Type | 2-mil (50 micron) | |
| Tensile Strength | Tensile Tester 2-in (51mm) jaw seperation; crosshead speed of 12 in/min. (5.1 mm/s), web direction | ≥ 4.5 lb/in | ≥ 0.8 kg/cm |
| Elongation | Instron Tensile Tester as above | ≥ 150% | |
| Shelf Life (In Box) | Ideal storage temperature 21°C and 50% relative humidity | 2 years from factory shipment | |
| Application Temperature Range | On clean, dry substrate | 40°F to 100°F | 4.4°C to 38°C |
| Service Temperature Range | On clean, dry substrate | -40°F to 175°F | -40°C to 79°C |
| Dimensional Stability | Shrinkage After 158°F (70°C), 48 hours | 5-mil | 0.13 mm |
| Peel Adhesion | PSTC-1, 15 min, 70°F (21°C) | 3.5 lbs/in | 0.625 kg/cm |
| Liner Release | TLMI Release at 90°, 300 in/min (760 cm/min) | 35 g/2 in | 6.89 g/cm |
